DRAM | TWELVE



twelve | model

The 'twelve' Loudspeaker from ART Loudspeakers utilises many features from our Reference Loudspeaker range.

'twelve' is a full range 3-way design that incorporates our unique multi-layered cabinet construction.

36mm thick walls provide an extremely strong stiff and inert enclosure. An internal mid enclosure is also employed to isolate any unwanted intrusions to the all critical midrange performance.

The 'twelve' is available in two versions:
Alnico Tweeter or Diamond tweeter, together with DRAM copper or DRAM Silver wire options.

As with the other DRAM models, the cabinets are available in any High Gloss polyester or automotive finishes.






specifications | twelve diamond

Speaker Type
Drivers


Crossover
Internal Wiring
Binding Posts
Frequency Response
Sensitivity
Impedance
Recommended power
Cabinet
Finishes
Overall dimensions
Weight packed

3 way Bass Reflex floor standing loudspeaker
1 x 300mm Bass- (treated paper)
1 x 220 mm Midrange (Papyrus Cone Alnico magnet)
1 x Tweeter 26mm Diamond Dome with Titanium voice coil former Hexatech magnet array
Jensen Copper foil Inductors and Capacitors
Dram Silver Reference
Silver Plated terminals
23Hz – 5o kHz ±3dB
90 dB/for 1 watt@1metre
8ohm nominal impedance
Min 8 watts
Multi-layer cold moulded cabinet
Piano Gloss and Polyester Finishes
1200mmH x 320mmD x 430mmW  (Cabinet)
60 kilos each



specifications | twelve ALNICO

Speaker Type
Drivers


Crossover
Internal Wiring
Binding Posts
Frequency Response
Sensitivity
Impedance
Recommended power
Cabinet
Finishes
Overall dimensions
Weight packed

3 way Bass Reflex floor standing loudspeaker
1 x 300mm Bass- (treated paper)
1 x 220 mm Mid-bass
1 x Tweeter 35mm Fabric Dome with alnico magnet
ART Wirewound Inductors and  Claritycap Capacitors
Dram Copper Reference
Silver Plated terminals
23Hz – 5o kHz ±3dB
90 dB/for 1 watt@1metre
8ohm nominal impedance
Min 8 watts
Multi-layer cold moulded cabinet
Piano Gloss and Polyester Finishes
1200mmH x 320mmD x 430mmW  (Cabinet)
60 kilos each


OTHER MODELS IN THE DRAM SERIES from art loudspeakers




Their are five different models in the DRAM series. To find out more about a particular model, please click on one of the models (pictures) on the right.
