DRAM | EIGHT



eight | model

As with the other DRAM models, the 'EIGHT' is a beautifully simple loudspeaker that will suit many musical fans.

The cabinet utilises our new multi-layered construction with a choice of two different levels of tweeter,  internal wire and components.

'EIGHT' has its Bass port firing down towards the integral stand allowing great flexibility in positioning of the speaker.

The cabinets are finished with high gloss polyester Lacquer in any RAL colour and can also have any automotive finish applied with the deep gloss.






specifications | eight diamond

Speaker Type
Drivers

Crossover
Internal Wiring
Binding Posts
Frequency Response
Sensitivity
Impedance
Recommended power
Cabinet
Finishes
Overall dimensions
Weight packed

2 way Bass Reflex Monitor loudspeaker
1 x 220 mm Mid -Bass (Paper Cone)
1 x Tweeter 26mm Diamond Dome with Titanium voice coil former (Hexatech magnet array)
Jensen Copper foil Inductors and Capacitors
Dram Silver Reference
Silver Plated terminals
28Hz – 2o kHz ±3dB
89 dB/for 1 watt@1metre
8ohm nominal impedance
Min 8 watts
Multi-layer cold moulded cabinet
Piano Gloss and Polyester Finishes
1060mmH x 320mmD x 305mmW  (Cabinet)
30 kilos each





specifications | eight alnico

Speaker Type
Drivers

Crossover
Internal Wiring
Binding Posts
Frequency Response
Sensitivity
Impedance
Recommended power
Cabinet
Finishes
Overall dimensions
Weight packed

2 way Bass Reflex Monitor loudspeaker
1 x 220 mm Mid-Bass (Paper Cone)
1 x Tweeter 35mm Fabric Dome with alnico magnet
ART wirewound Inductors and ICW Capacitors
Dram Copper Reference
Silver Plated terminals
28Hz – 2o kHz ±3dB
89 dB/for 1 watt@1metre
8ohm nominal impedance
Min 8 watts
Multi-layer cold moulded cabinet
Piano Gloss and Polyester Finishes
1060mmH x 320mmD x 305mmW  (Cabinet)
30 kilos each


OTHER MODELS IN THE DRAM SERIES from art loudspeakers




Their are five different models in the DRAM series. To find out more about a particular model, please click on one of the models (pictures) on the right.
