monitor | model

The 'MONITOR' is an itch we have been wanting to scratch for some time now.

We have been developing a new multi-layered cabinet construction which results in an extremely inert and stiff enclosure.

For this speaker we created an upward firing Bass reflex port allowing huge flexibility in the placement of the speaker.

Available with either DRAM copper or DRAM silver wire, these speakers can be purchased and later upgraded to a higher spec model. The cabinets are finished with high gloss polyester Lacquer in any RAL colour and can also have any automotive finish applied with the deep gloss.






specifications | monitor diamond

Speaker Type
Drivers

Crossover
Internal Wiring
Binding Posts
Frequency Response
Sensitivity
Impedance
Recommended power
Cabinet
Finishes
Overall dimensions
Weight packed

2 way Bass Reflex Monitor loudspeaker
1 x 220 mm Mid -Bass (Treated paper 30mm voice coil)
1 x Tweeter 26mmDiamond Dome with Titanium voice coil former  Hexatech magnet array
Jensen Copper foil Inductors and Capacitors
Dram Silver Reference
Silver Plated terminals
32Hz – 5o kHz ±3dB
90 dB/for 1 watt@1metre
8ohm nominal impedance
Min 8 watts
Multi-layer cold moulded cabinet
Piano Gloss and Polyester Finishes
550mmH x 320mmD x 305mmW  (Cabinet)
30 kilos each





specifications | monitor alnico

Speaker Type
Drivers

Crossover
Internal Wiring
Binding Posts
Frequency Response
Sensitivity
Impedance
Recommended power
Cabinet
Finishes
Overall dimensions
Weight packed

2 way Bass Reflex Monitor loudspeaker
1 x 220 mm Mid-Bass (Paper Cone)
1 x Tweeter 35mm Fabric Dome with alnico magnet
ART wirewound Inductors and ICW Capacitors
Dram Copper Reference
Silver Plated terminals
32Hz – 5o kHz ±3dB
89 dB/for 1 watt@1metre
8ohm nominal impedance
Min 8 watts
Multi-layer cold moulded cabinet
Piano Gloss and Polyester Finishes
550mmH x 320mmD x 305mmW  (Cabinet)
30 kilos each


OTHER MODELS IN THE DRAM SERIES from art loudspeakers




Their are five different models in the DRAM series. To find out more about a particular model, please click on one of the models (pictures) on the right.

 DRAM 15

DRAM 15

 DRAM 12

DRAM 12

 DRAM 10

DRAM 10

 DRAM 8

DRAM 8

 DRAM Monitor
